Description
ITEM DESCRIPTION
The Illustra Essentials 2MP IR Mini-Dome camera offers the latest
compression technologies by supporting both H.265 and H.264 codecs
resulting in reduced bandwidth and storage requirements. The Mini-Dome
is able to be configured in resolutions ranging from 1080P to CIF to
support a variety of recording environments. Rated IP67 for an
additional degree of environmental protection, the Mini-Dome exceeds
previous generations of Illustra Essentials cameras.
Features
- 1080p Resolution for HD Images
- Manage Bandwidth Resources with H.264 and MJPEG Dual-Stream Encoding
- Up to 30 Frames Per Second for Seamless Video Streaming
- IP67 Environmental Rating to Protect against Dust and Water
- 3.6mm Fixed Lens Continuously Monitors Areas of Interest
- IR Illuminators Deliver Clear Video when Viewing Dark Scenes up to 98ft
- True Day/Night Functionality for Quality Video Recording in Low Light Conditions
- Wide Dynamic Range to Simultaneously View High-Contrasting Areas
MODEL | IES02CFBCWIYB |
---|---|
Manufacturer | American Dynamics |
Features | Auto Gain Control, Back Light Compensation, Day/Night, Digital Noise Reduction, On Screen Display Menu, ONVIF, Privacy Masking, Weather Resistant, Wide Dynamic Range |
Camera Signal | Network IP |
Connection Type | Wired |
Infrared Distance | 0~98 Feet |
Resolution | 2 Megapixel |
Lens Type | Fixed |
Mount Type | Ceiling, Wall |
Compression Method | H.264, H.265 |
Durability | Weather Resistant |
Voltage | 12vDC, PoE |
Automatic Gain Control (AGC) | Auto/Manual |
Dimensions (W x H) | 108mm x 84mm (4.25in x 3.31in) |
Electronic Shutter | Auto/Manual, 1/3~1/100000s |
Minimum Scene Illumination | Color: 0.08Lux/F2.0; IR on: 0Lux/F2.0 |
Operating Temperature | -30°C to +55°C |
OSD Menu | Chinese (simplified), Dutch, English (default), French, German, Italian, Portuguese, Spanish |
Power Consumption | <4.12W |
Privacy Zone | Up to 4 areas |
Protocols | IPv4/IPv6, HTTP, TCP/IP, UDP, UPnP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, QoS |
S/N Ratio | More than 45dB |
Weatherproof | IP67 |
Digital Noise Reduction | 3D |
Angle of View | H: 110°/83° V: 56°/44° |
Back Light Compensation | Yes |
Automatic White Balance | Auto/Manual |
IR Distance | 30m/98.42ft |
Auto Gain Control | Yes |
Day/Night | Yes |
Digital Noise Reduction | Yes |
Back Light Compensation | Yes |
On Screen Display Menu | Yes |
Privacy Masking | Yes |
Wide Dynamic Range | Yes |
ONVIF | Yes |
